| 规格： | Specification: |
| 电压/Voltage | LPDDR1 1.8V
LPDDR2 1.8V/1.2V LPDDR4X 1.1V/0.6V |
| 温度/Temperature | -40℃ ~ 85℃ |
| 容量/ Density | LPDDR1 512Mb/1Gb/2Gb
LPDDR2 1Gb/2Gb/4Gb LPDDR4X 1Gb/2Gb/8Gb |
| 封装/Package | LPDDR1 60/90ball FBGA
LPDDR2 134ball FBGA LPDDR4X 200ball FBGA |
| 速度/Speed | LPDDR1 166MHz/200MHz
LPDDR2 400MHz/533MHz LPDDR4X 1600MHz/2133MHz |
| 线宽/Bus Width | LPDDR1 x16/x32
LPDDR2 x16/x32 LPDDR4X x16/x32 |
东芯的LPDDR系列产品具有LPDDR1, LPDDR2, LPDDR4X三个系列。 LPDDR1的核心电压与IO电压均低至1.8V，LPDDR2的VDDCA/VDDQ低至1.2V，LPDDR4X的VDDQ更低至0.6V，因此非常适合应用在各种移动设备中。LPDDR系列产品将广泛应用于可穿戴/遥控设备等便携式产品。
Dosilicon’s LPDDR has several products in three series,ie.,LPDDR1.LPDDR2 and LPDDR4X.The core voltage and IO voltage of LPDDR1 is as low as 1.8V, while the VDDCA / VDDQ of LPDDR2 can even go down to 1.2V, and the VDDQ of LPDDR4X can even go down to 0.6V,so they are very suitable for various mobile devices.Dosilicon will apply its LPDDR product extensively to wearable/remote devices and other portable products.
| Type | Part Number | Density | Voltage | Speed(MHz/CLK) | Temp. Range | PKG Type | Datasheet |
|---|---|---|---|---|---|---|---|
|
LPDDR4X |
DSF1G16VAA-4CDI | 1Gb | 1.1V | 1600MHz | -40℃~85℃ | FBGA 200 | Contact us |
|
DSF2G32VMA-4CDI |
2Gb |
||||||
|
DSF2G16VMC-4CDI |
|||||||
|
DSF8G32VMA-4ADI |
8Gb |
2133MHz |
